PANEL NAME: LIQUID WASTE RECYCLING
STATUS DISPLAY FUNCTION OVERVIEW:
This passive display monitors flow through an intership
water reclamation system. There are 19 primary
pump/transfer stations and three collection points.
Standard flow is 12,000 gallons/hour with an expansion
capacity of 2,000 additional. Waste water is routed to
the treatment facility on deck 6 for molecular
separation. Using this closed-loop system each gallon of
water is used/recycled eight times per day. In the event
of damage or overloading the affected station will blink
red until acknowledged.
CALIBRATION PROCEDURE:
None |
